LEDDownlightCo-E2 Rd100-4/8W-830/840

Electrical data

Nominal voltage	220|240 V
Voltage type	AC
Power factor	0.7
Max. system power	8 W
Max. inrush current	12.7 A
Inrush time	148
Frequency	50|60 Hz
Max. number of luminaires per miniature circuit breaker B16 (MCB)	64
Max. number of luminaires per miniature circuit breaker C16 (MCB)	107

Photometrical data

Colour temperature	3000|4000 K
Equivalent to	CFL 1x18W
Colour consistency (SDCM)	4
Luminaire efficacy	110 lm/W
Colour rendering index (CRI)	> 80

Light technical data

Beam angle	100°
Beam angle	100°
UGR	22

Lifespan

Lifetime (L70)	70000 h
Lifetime (L80)	50000 h
On-/Off-cycles	100000

Capabilities

Dimmability	On-Off

Certificates and standards

Degree of protection (IP)	IP20
Protection class according to IEC 61140	II
Impact strength	IK03
Glow wire test	650°C
IP recessed part	IP20
Risk group (EN 62471)	RG0

Type of control gear	LED operating device current-controlled
With control gear	Yes
Driver failure rate (at 5,000 hrs)	1%
Input current	0.08 A

Housing colour	White
Optical material	PC
Cover material	PS
Finishing	White RAL9003

Length	115 mm
Width	115 mm
Height/depth	35 mm
Outer diameter	115 mm

Application temperature	25°C
Storage environment	-25|50°C
Operating temperature	-10|45°C
