LEDWaterproof-B3 L15-45/60W-840/857

Electrical data

Nominal voltage	220|240 V
Voltage type	AC/DC
Power factor	0.9
Max. system power	60 W
Max. inrush current	16.8 A
Inrush time	90
Displacement factor (DF)	≥ 0.9
Including emergency lighting	No
Frequency	50|60 Hz
Nominal voltage DC	180|260 V
Max. number of luminaires per miniature circuit breaker B16 (MCB)	26
Max. number of luminaires per miniature circuit breaker C16 (MCB)	44

Photometrical data

Colour temperature	4000|5700 K
Equivalent to	TL 1/2x58W
Colour consistency (SDCM)	4
Luminaire efficacy	135 lm/W
Colour rendering index (CRI)	> 80

Light technical data

Beam angle	120°
Beam angle	120°

Lifespan

Lifetime (L70)	60000 h
Lifetime (L80)	30000 h
On-/Off-cycles	100000

Capabilities

Dimmability	On-Off

Certificates and standards

Degree of protection (IP)	IP65
Protection class according to IEC 61140	II
Impact strength	IK08
Glow wire test	650°C
Risk group (EN 62471)	RG0

Type of control gear	LED operating device current-controlled
With control gear	Yes
Driver failure rate (at 5,000 hrs)	0.5%
Input current	0.371 A
Max. input cable diameter	7|11 mm
Wirethrough	Yes
Internal wiring (mm2)	3x1.5

Housing colour	Grey
Optical material	Polycarbonate
Cover material	Polycarbonate
Finishing	Grey RAL 7035
Coastal proof	No

Length	1533 mm
Width	59 mm
Height/depth	56 mm

Application temperature	25°C
Storage environment	-30|50°C
Operating temperature	-20|45°C
